From there, choose a transparent LED screen that suits your needs and get high quality projection products.
"Huge 30m2 transparent LED screen at Vincom Tran Duy Hung"
Before we discuss transparent led screen resolution , you need to know what is Pixel pitch?
Pixel pitch, also known as pixel distance, means the distance in (mm) from the center of one LED bulb to the center of the adjacent LED bulb.
"Pixel pitch is the pixel distance"
The smaller the pixel pitch, the larger the LED screen resolution, so the P6 will have a higher resolution than the P10.
“Please read the article Everything about Pixcel pitch of transparent LED screens to better understand Pixel Spacing”
The led module with a led screen frame uses Surface-mount technology (SMT) - surface gluing technology and mounting LED chips on the circuit board (PCB).
It can be connected together to form a large LED screen
"Design of transparent led module"
“To better understand the uses and characteristics of LED modules, you should read the article Transparent LED Screen Module: Structure and Functions ”
Now we will explain how to calculate pixels per led cabinet (another name for led module).
Let's take the example of a P2.5 LED screen with the dimensions of each module being 320mm x 160mm (width x height).
The P2.5 screen has a pixel pitch of 2.5mm.
First we will calculate the resolution of the width which will be equal to the width divided by pixel pitch: 320/2.5 = 1280 pixels .
Same with height: 160/2.5 = 64 pixels .
So the pixels of each LED module are : 128x64 pixels .
The question is, after obtaining the pixels of each LED module, what is the resolution of the entire transparent LED screen?
"Depending on installation needs, choose a module with appropriate resolution"
If the P2.5 glass LED screen has dimensions of 3200mm x 3200mm.
To calculate the number of LED modules needed, we divide the screen width by the width of the LED module.
We have: 3200/320 = 10 (horizontal panels), meaning the width requires 10 modules
Similar to height: 3200/160 = 20 (height of panels) means the height requires 20 modules
From here we can calculate the transparent LED screen pixels with dimensions: 3200mm x 3200mm
Take the pixels of a module and multiply it by the calculated number of LED modules:
So we get a transparent LED screen resolution of 1280x1280 pixels
Please contact us for the most accurate advice and support!
